Monitor Audio C3L Ceiling Speaker

£750.00

The Monitor Audio C3L is a premium in-ceiling speaker from the Creator Series, designed for high-fidelity audio reproduction. It features a three-way driver system, including a 9" RDT III bass driver, a 4" IDC II midrange driver, and a 1" IDC II tweeter with a UD Waveguide II. This configuration offers an impressive frequency response of 45Hz to 35kHz, ensuring detailed and balanced sound. The speaker also includes advanced features like the Quik-Link connector for easy installation and the Tri-Grip II mounting system for secure fitting. It is ideal for both home theater setups and commercial installations where superior audio quality is desired.

Technical Specifications

Frequency Response: 45Hz - 35kHz
Impedance: 6 ohms
Sensitivity: 89 dB (1W@1M)
Power Handling: 60 - 225 watts

Drivers: 9-inch RDT III bass driver, 4-inch IDC II midrange driver and 1-inch IDC II tweeter

Overall Dimensions (with grille): 278 mm x 161 mm
Cut-Out Dimensions: Diameter 248 mm
Mounting Depth: 157 mm
Weight: 5 kg

Monitor Audio Lifetime Warranty

Applications

The Monitor Audio C3L is versatile and ideal for various applications:

Home Theaters: It is perfect for creating immersive surround sound setups, offering detailed and dynamic audio that enhances the cinematic experience.

Multi-Room Audio Systems: The C3L is suitable for distributing high-quality audio throughout a home or commercial space, providing consistent sound quality in different rooms.

Commercial Spaces: Its robust construction and high power handling make it suitable for use in environments like restaurants, retail stores, and conference rooms, where reliable and high-quality audio is essential.

Three-Way Driver Configuration

The C3L features a sophisticated three-way driver system, optimising the audio performance by dedicating specific drivers to distinct frequency ranges. This design ensures a rich and balanced sound profile across the audio spectrum.

9" RDT III Bass Driver

The 9" RDT III (Rigid Diaphragm Technology) bass driver is designed to deliver deep, powerful bass with minimal distortion. The driver utilises a composite cone structure made from C-CAM (Ceramic-Coated Aluminium/Magnesium), known for its excellent stiffness-to-weight ratio. This material combination ensures that the bass is tight, controlled, and accurate, providing a strong foundation for all types of music and audio content.

4" IDC II Midrange Driver

The 4" midrange driver in the C3L utilizes the IDC II (Inverted Dual Concentric) technology, which pairs the midrange driver with the tweeter in a compact, concentric layout. This design offers a cohesive sound image and smooth integration between the midrange and high frequencies. The midrange driver handles critical audio details like vocals and instruments, delivering them with clarity and precision.

1" IDC II Tweeter

The 1" gold dome C-CAM tweeter, part of the IDC II array, provides extended high-frequency response. This tweeter is optimised to deliver clear and detailed highs, free from harshness or distortion. The inclusion of a UD Waveguide II (Uniform Dispersion Waveguide) ensures that the high frequencies are evenly distributed across the listening area, resulting in a wide and immersive soundstage.

Frequency Response and Sensitivity

Frequency Response: The C3L offers a broad frequency response range from 45Hz to 35kHz, ensuring it captures the full spectrum of sound from deep bass to airy treble. This wide range makes it suitable for reproducing various audio content, including music, movies, and more.

Sensitivity: With a sensitivity of 89 dB, the C3L efficiently converts power into sound, making it capable of producing high output levels even with moderate power inputs. This characteristic is essential for dynamic and impactful sound performance.

Power Handling and Impedance

Power Handling: The speaker can handle up to 150W RMS power, with a recommended amplifier range of 60W to 150W. This power handling capacity ensures that the C3L can deliver robust and dynamic sound without distortion, even at high volumes.

Impedance: The nominal impedance of 6 ohms makes the C3L compatible with a wide range of amplifiers, ensuring flexibility in system integration.

Quik-Link Connector

The patented Quik-Link connector simplifies the installation process, providing a quick and reliable connection to the audio system. This feature is especially useful in professional installations, where efficiency and reliability are crucial.

Tri-Grip II Mounting System

The Tri-Grip II mounting system is designed to secure the speaker firmly in place, minimising vibrations and potential audio distortions. This system uses a three-point clamping mechanism that not only ensures a secure fit but also facilitates easy alignment during installation. This mounting system is particularly beneficial in maintaining the speaker's performance by providing a stable mounting environment.

Design and Aesthetics

The C3L boasts a sleek, low-profile design, allowing it to blend seamlessly with any ceiling decor. The speaker comes with a paintable grille, enabling it to match the surrounding environment, making it an unobtrusive yet powerful addition to any space. The aesthetic appeal is matched by the robust build quality, ensuring that the speaker not only looks good but also stands the test of time.

Tri-Grip II

Tri-Grip II is an advanced mounting system used in Monitor Audio's Creator Series speakers. It features a three-point fixing mechanism that provides a secure and stable attachment to ceilings or walls. This system minimises vibrations and ensures optimal sound quality. The Tri-Grip II also allows for quick and easy installation, making it user-friendly for both professional installers and DIY enthusiasts. It's designed to accommodate various architectural settings and ensure a flush, aesthetically pleasing finish.

Quick-Link

Quick-Link is an innovative feature designed for easy and efficient speaker installation. This connector system simplifies the wiring process, allowing for quick and secure connections between the speaker and the amplifier or receiver. It is particularly beneficial in multi-speaker setups, where it significantly reduces the time and effort required for installation. The Quick-Link system is a standard feature in Monitor Audio's Creator Series, ensuring reliable and hassle-free installations across various environments.

Tier 1 Ceiling Speakers

A versatile range of small, medium and large speakers designed for cost-effective installations, prioritising product simplicity and reliable acoustic performance.

Features
Two-way arrangement
C-CAM mid-bass drivers
C-CAM tweeter with UD Waveguide I
Tri-Grip II
Quik-Link

Tier 2 Ceiling Speakers

This range of small, medium and large in-ceiling speakers retains the engineering excellence of Tier 1 while offering enhanced acoustic performance. It includes additional features like boundary correction, high-frequency cut/boost, and the dual-stereo T2X, providing greater flexibility in speaker placement.

Features
Two-way arrangement
RST II mid-bass drivers
C-CAM tweeter with UD Waveguide II
Controlled Performance
T2X-Model
Tri-Grip II
Quik-Link

Tier 3 Ceiling Speakers

This high-performance range of medium and large in-ceiling speakers builds on the engineering excellence of Tier 2, offering enhanced acoustic performance. It includes additional features for versatile speaker placement, such as boundary correction and mid/high-frequency cut/boost options, along with advanced acoustic technologies.

Features
Three-way arrangement
RDT III bass drivers
IDC II coaxial mid/tweeter drivers with UD Waveguide II
Controlled Performance
Tri-Grip II
Quik-Link

Monitor Audio Creator Series Speakers

Monitor Audio Creator Series ceiling speakers offer a range of high-quality, in-ceiling audio solutions designed for versatile applications. These speakers feature advanced C-CAM (Ceramic-Coated Aluminum/Magnesium) drivers, including mid-bass drivers and tweeters, which provide exceptional sound clarity and detail. Creator Series ceiling speakers are ideal for both residential and commercial installations.

View the full range of Creator Series speakers
