The Trinnov Amplitude 16 is a high-performance 16-channel power amplifier designed for demanding home cinema and immersive audio systems. Developed to complement Trinnov's Altitude range of AV processors, it combines substantial power, sophisticated engineering and flexible installation options within a compact rack-mounted chassis.
Using an efficient Class D amplification architecture, the Amplitude 16 delivers 200 watts per channel into 8 ohms and 400 watts per channel into 4 ohms, with ratings specified at 1kHz and less than 0.1% THD+N. For applications requiring greater output, adjacent channels can be bridged to provide up to 800 watts into 8 ohms or 1,000 watts into 4 ohms, subject to the specified operating conditions.
Its dual eight-channel architecture incorporates two independent power supplies, helping provide stable power delivery across the amplifier's 16 channels. This design makes it particularly well suited to immersive home cinema systems where multiple loudspeakers need to be driven from a central equipment rack. Connectivity is designed with professional installations in mind. Two DB25 analogue input connectors provide connections for all 16 channels, helping simplify cable management, while an optional Dante input board adds network audio connectivity with support for AES67. Trigger input and output connections provide additional flexibility when integrating the amplifier into a wider AV system.
Carefully gain-matched to Trinnov Altitude processors, the Amplitude 16 provides a natural amplification partner for systems built around the Altitude 16, Altitude 32 or Altitude CI. Together, they provide a powerful foundation for bespoke home cinemas, with the flexibility to configure amplification around the loudspeakers and requirements of each installation.
